Coupling Medium Pressure
Adaptors - High Pressure Systems
| MEDIUM PRESSURE | |||||
| Catalouge # | A FEMALE END |
B FEMALE END |
F-HEX Inch mm | B mm | |
| HSCMP/20-XF4-XF4 | XF4 | XF4 | 5/8 | 15.9 | 41.4 |
| HSCMP/20-XF4-XF6 | /XF4 | XF6 | 3/4 | 19.0 | 44.5 |
| HSCMP/20-XF4-XF12 | XF4 | XF9 | 1 | 25.4 | 50.8 |
| HSCMP/20-XF4-XF16 | XF4 | XF12 | 1-3/8 | 35.0 | 57.2 |
| HSCMP/XF4-ZF4 | XF4 | XF16 | 1-3/4 | 44.5 | 69.9 |
| HSCMP/20-XF4-ZF6 | XF4 | XF4 | 3/4 | 19.0 | 35.1 |
| HSCMP/20-XF4-ZF9 | XF4 | XF6 | 1 | 25.4 | 41.4 |
| HSCMP/20-ZF4-ZF9 | XF4 | XF9 | 1-3/8 | 35.0 | 47.8 |
| HSCMP/20-XF4-ZF5 | XF4 | XF5 | 1 | 25.4 | 54.1 |
| HSCMP/20-XF4-ZF16-40 | XF4 | XF6 | 1-3/4 | 44.5 | 69.9 |
| HSCMP/20-XF6-XF6 | XF6 | XF6 | 3/4 | 19.0 | 44.5 |
| HSCMP/20-XF6-XF9 | XF6 | XF9 | 1 | 25.4 | 50.8 |
| HSCMP/20-XF6-XF12 | XF6 | XF12 | 1-3/8 | 35.0 | 57.2 |
| HSCMP/20-XF6-XF16 | XF6 | XF16 | 1-3/4 | 44.5 | 73.0 |
| HSCMP/20-XF6-ZF4 | XF6 | XF4 | 3/4 | 19.0 | 41.4 |
| HSCMP/20-XF6-ZF6 | XF6 | XF6 | 1 | 25.4 | 50.8 |
| HSCMP/20-XF6-ZF | XF6 | XF9 | 1-3/8 | 35.0 | 50.8 |
| HSCMP/20-XF6-ZF5-150 | XF6 | XF5 | 1 | 25.4 | 57.2 |
| HSCMP/20-XF6-ZF16-40 | XF6 | XF6 | 1-3/4 | 44.5 | 73.0 |
| HSCMP/20-XF9-20XF9 | XF9 | XF9 | 1 | 25.4 | 54.1 |
| HSCMP/20-XF9-20XF12 | XF9 | XF12 | 1-3/8 | 35.0 | 63.5 |
| HSCMP/20-XF9-20XF16 | XF9 | XF16 | 1-3/4 | 44.5 | 76.2 |
| HSCMP/20-XF9-20ZF4 | XF9 | XF4 | 1 | 25.4 | 50.8 |
| HSCMP/XF9-20ZF6 | XF9 | XF6 | 1 | 25.4 | 50.8 |
| HSCMP/20-XF9-20ZF9 | XF9 | XF9 | 1-3/8 | 35.0 | 57.2 |
| HSCMP20-XF9-ZF5-150 | XF9 | XF5 | 1 | 25.4 | 63.5 |
| HSCMP/20-XF12-XF12 | XF12 | XF12 | 1-3/8 | 35.0 | 63.5 |
| HSCMP/20-XF12-XF16 | XF12 | XF16 | 1-3/4 | 44.5 | 76.2 |
| HSCMP/20-XF12-ZF4 | XF12 | XF4 | 1-3/8 | 35.0 | 63.5 |
| HSCMP/20-XF12-ZF6 | XF12 | XF6 | 1-3/8 | 35.0 | 60.33 |
| HSCMP/20-XF12-ZF9 | XF12 | XF9 | 1-3/8 | 35.0 | 69.9 |
| HSCMP/20-XF12-ZF5-150 | XF12 | XF5 | 1-3/8 | 35.0 | 69.9 |
| HSCMP/20-XF16-XF16 | XF16 | XF16 | 1-3/4 | 44.5 | 88.9 |
| HSCMP/20-XF16-ZF4 | XF16 | XF4 | 1-3/4 | 44.5 | 69.9 |
| HSCMP/20-XF16-ZF6 | XF16 | XF6 | 1-3/4 | 44.5 | 73 |
| HSCMP/20-XF16-ZF9 | XF16 | XF9 | 1-3/4 | 44.5 | 82.6 |
| HSCMP/20-XF16-ZF5-150 | XF16 | XF5 | 1-3/4 | 44.5 | 82.6 |
