Union
Hydraulic Fittings
UNION |
| SERIES |
Part No. |
Tube
OD
|
F1
|
F |
L |
A |
| LL |
HSU/04LL
|
4 |
10 |
9 |
31 |
12 |
| Very light |
HSU/06LL |
6 |
12 |
11 |
32 |
9 |
| PN 100 |
HSU/08LL |
8 |
14 |
12 |
35 |
12 |
| |
HSU/10LL |
10 |
17 |
14 |
35 |
12 |
| |
HSU/12LL |
12 |
19 |
17 |
35 |
11 |
| L |
HSU/06L |
6 |
14 |
12 |
39 |
10 |
| light |
HSU/08L |
8 |
17 |
14 |
40 |
11 |
| PN315 |
HSU/10L |
10 |
19 |
17 |
42 |
13 |
| |
HSU/12L |
12 |
22 |
19 |
43 |
14 |
| |
HSU/15L |
15 |
27 |
24 |
46 |
16 |
| |
HSU/18L |
18 |
32 |
27 |
48 |
16 |
| PN 160 |
HSU/22L |
22 |
36 |
32 |
52 |
20 |
| |
HSU/28L |
28 |
41 |
41 |
54 |
21 |
| |
HSU/35L |
35 |
50 |
46 |
63 |
20 |
| |
HSU/42L |
42 |
60 |
55 |
66 |
21 |
| S |
HSU/06S |
6 |
17 |
14 |
45 |
16 |
| Heavy |
HSU/08S |
8 |
19 |
17 |
47 |
18 |
| PN 630 |
HSU/10S |
10 |
22 |
19 |
49 |
17 |
| |
HSU/12S |
12 |
24 |
22 |
51 |
19 |
| |
HSU/14S |
14 |
27 |
24 |
57 |
22 |
| PN 400 |
HSU/16S |
16 |
30 |
27 |
57 |
21 |
| |
HSU/20S |
20 |
36 |
32 |
66 |
23 |
| |
HSU/25S |
25 |
46 |
41 |
74 |
26 |
| |
HSU/30S |
30 |
50 |
46 |
80 |
27 |
| PN 315 |
HSU/38S |
38 |
60 |
55 |
90 |
29 |
