Condensate Pot
Accessories
Condensate is steam that has been condensed back into water. When the condensate enters the boiler feed pump additional chemicals are added and the product is now called boiler feed water.
FEATURES:-
- Use as liquid or condensate traps, seal pots, vapor chambers and knockout pots.
- All connectors are protected with plastic plugs.
- Chambers are made from seamless carbon steel pipe and weld caps. All pipe connections are #3000 half-couplings mounted on 90 Degree angle. Extra connections can be furnished upon customer request.
- Heat code traceability provided upon request.
- All welding as per ASME SEC. IX
- All butweld joints will be 100% radiographed and fillet weld will be D.P. tested.
TECHNICAL SPECIFICATIONS ::-
- Size: pipe size 2",3",4" and larger size upon request.
- Length : Pipe length 8", 10", 12" and larger length upon request.
- Working pressure: 6000 PSI (413 Bar)
- Material of construction: SS 316, SS 304,ASTM A 106 Gr B
- Optional Sour Gas service pots are available confirming to NACE Std. MR-01-75
- Pipe Schedule: 40, 80, 160, XX seamless pipe.
- Chamber as per ISA RP3
- NPT as per ANSI B2.1 taper pipe thread 1/2" furnished.
- Socketweld as per ANSI B16.11
- Buftweld as per ANSI B16.9
- All chamber are 100% Factory tested prior to shipment.
APPLICATION:-
- Used in process systems. Which are systems difficult to shut off due to solid contents dust, rust, dirt, etc.
TESTING:-
- Hydrostatic shell test is performed at 1.5 times the working pressure.
| Material | Schedule-40 | Schedule-80 | Schedule-160 | |||
| Pressure Test | Pressure Test | Pressure Test | ||||
| Kg./cm² | PSI | Kg./cm² | PSI | Kg./cm² | ||
| A106 Gr.B | 80 | 1150 | 125 | 1800 | 210 | 3000 |
| AISI 316 | 95 | 1350 | 155 | 2200 | - | - |
