Ball Valve
FEATURES OF HIGH PRESSURE BALL VALVE (TUBE END)
- Bar Stock design.
- Bi-directional ball valve.
- Panel mounting option available.
- Pressure rating : 6000 PSI.
|
No
|
Description
|
Material of Construction |
Qty. |
| 1 |
Body |
SS 316 |
1 |
| 2 |
Adopter |
SS 316 |
2 |
| 3 |
Ball |
SS 316 |
1 |
| 4 |
Stem |
SS 316 |
1 |
| 5 |
Seats |
P.T.F.E. |
2 |
| 6 |
Joint Seal |
Viton |
2 |
| 7 |
Gland Seal |
P.T.F.E. |
1 |
| 8 |
Back-up Seal |
P.T.F.E. |
1 |
| 9 |
Retainer |
SS304 |
1 |
| 10 |
Stop Pin |
SS304 |
1 |
| 11 |
Washer |
CS Plated |
1 |
| 12 |
Stem Nut |
CS Plated |
1 |
| 13 |
Handle |
CS Plated |
1 |
| 14 |
Sleeve |
P.V.C. |
1 |
| 15 |
Nut |
SS316 |
2 |
| 16 |
Front Ferrule |
SS316 |
2 |
| 17 |
Back Ferrule |
SS316 |
2 |
|
Part No
.
|
INLET/OUTLET
OD |
Dimension
|
Cv |
|
|
HSABV/6K/T-2l |
1/8" |
72 |
25 |
28 |
2.5 |
37 |
95 |
0.29 |
| HSABV/6K/T-4l |
1/4" |
80 |
25 |
30 |
4.8 |
38 |
95 |
1.30 |
| HSABV/6K/T-6l |
3/8" |
85 |
28 |
32 |
7 |
38 |
95 |
2.60 |
| HSABV/6K/T-8l |
1/2" |
97 |
32 |
38 |
10 |
52 |
135 |
9.85 |
| HSABV/6K/T-12l |
3/4" |
110 |
40 |
45 |
15 |
55 |
135 |
16.88 |
| HSABV/6K/T-16l |
1" |
120 |
42 |
45 |
19 |
55 |
150 |
18.80 |
| HSABV/6K/T-4M |
4mm |
72 |
25 |
28 |
2.5 |
37 |
95 |
0.29 |
| HSABV/6K/T-6M |
6mm |
80 |
25 |
30 |
4.8 |
38 |
95 |
1.30 |
| HSABV/6K/T-10M |
10mm |
85 |
28 |
32 |
7 |
38 |
95 |
2.60 |
| HSABV/6K/T-12M |
12mm |
97 |
32 |
38 |
10 |
52 |
135 |
9.85 |
| HSABV/6K/T-18M |
18mm |
110 |
40 |
45 |
15 |
55 |
135 |
16.88 |
| HSABV/6K/T-25M |
25mm |
120 |
42 |
45 |
19 |
55 |
150 |
18.80 |
PRESSURE TEST:
- Every Ball valve is factory tested.
Note : Dimensions are reference only and are subject to change.
