| No |
FILLABLE DRY VERSION
|
| 1 |
Accuracy |
±1.0 % F.S. |
| 2 |
Ambient Temperature |
-25°C to 65°C |
| 3 |
Process Temperature |
Maximum 270°C /Maximum +400°C(with SS 316 L internals) |
| 4 |
Operating Pressure |
Maximum 75% of the full Scale Value |
| 5 |
Over Pressure Limit : Full Scale Value : |
Full Scale Value,30% for pressure ranges < 60 kg/cm2,25% for pressure ranges = 100 kg/cm2,15% for pressure ranges > 100 kg/cm2 |
| 6 |
Protection |
IP 65 / IP 55 |
| 7 |
Bourdon |
Stainless Steel 316 |
| 8 |
Movement |
Stainless Steel 304 |
| 9 |
Socket Material |
Stainless Steel 316 |
| 10 |
Case & Bezal |
Stainless Steel 304 |
| 11 |
Dial |
Aluminum, Black graduation on White background, |
| 12 |
Pointer |
AIuminum BIack CoIoured Micrometer Zero adjustable |
| 13 |
Window |
Glass 4.00mm thick |
| 14 |
Gasket |
EPDM |
| 15 |
Blow off Disc |
EPDM |
| 16 |
Joints |
TIG argon are welding |
